FK-RVPXKU-M2
◆ | Standard 6U 5HP VPX architecture products, RAID 0 of 2 set group, providing multiple high -speed data interfaces to the outside world; |
◆ | Adopting Fengke NVME storage architecture, FTP or network disk access functions can be provided through Gigabit/10,000 -Dibin port ports. Through the PCIE interface, you can directly read and write the storage data data. There is no need to transfer; |
◆ | It has the characteristics of high bandwidth, large capacity, and providing standard EXFAT file systems. It can be widely used in data collection records and data management in related fields; |
Download：Product specifications
Product features
-
Standard 6 after u VPX architecture -
8 TB storage capacity -
3 gb/S memory bandwidth -
For exFAT file system
Detailed parameters
| Product form | Standard 6u VPX rear insertion architecture, height 5HP |
| Storage | Support 2 M.2 interface NVME SSD; Standard Edition 2TB, Maximum 8TB supports 8TB |
| Storage bandwidth | Continuous stable record bandwidth ≥3GB/s; continuous stable reading bandwidth ≥ 3GB/s |
| Data interface | Backboard: 8th road Gth, support SRIO, Aurora protocol |
| Control interface | Front panel: 1st Wanzaro Pass, 1 Gigabit Network port; PCIE3.0 X 4 |
| File management | Standard file system (EXFAT file system) |
| Control protocol | The network adopts a standard FTP communication protocol; supports standard FTP tools to access file access |
| Download bandwidth | Gigabit network port ≥100MB/s; 10,000MB/s |
| Software function | Real -time recording functions, data release functions, data access, file online management function, self -test and fault detection function, abnormal tolerance protection mechanism and other functions. |
| Operating temperature | Standard temperature: 0 ℃ to+55 ℃ Military temperature: -40 ° C to+70 ° C (optional, only partial hard disk, decreased bandwidth) |
| Cooling method | Compatible wind and cold and cold, support structure customization |
| Consumption | Full load run ≤30W |
| Size | 233.35mm × 81.5mm ×25mm |
Block diagram
Ordering Guide
| Serial number | Order model | Configuration |
| 1 | FK-RVPXKU-M2S1-2T | 2TB storage capacity, ≥2GB bandwidth |
| 2 | FK-RVPXKU-M2S2-2T | 2TB storage capacity, ≥3GB bandwidth |
| 3 | FK-RVPXKU-M2S1-4T | 4TB storage capacity, ≥2GB bandwidth |
4 | FK-RVPXKU-M2S1-8T | 8TB storage capacity, ≥2GB bandwidth |
