FK-LRMKU-M2
◆ | Standard LRM architecture products, 2 disk group RAID 0, provide multiple high -speed data interfaces to the outside world; |
◆ | Adopting Fengke NVME storage architecture, FTP or network disk access function can be provided through Gigabit/Mercedescent network ports; |
◆ | It has the characteristics of bandwidth, low power consumption, and providing standard EXFAT file systems, and can widely apply data collection records and data management in related fields; |
Product features
-
Standard LRM structure -
8 TB storage capacity -
3 gb/S memory bandwidth -
For exFAT file system
Detailed parameters
| Product form | Standard LRM board card architecture |
| Storage | Support 2 M.2 interface NVME SSD; Standard Edition 2TB, Maximum 8TB supports 8TB |
| Storage bandwidth | Continuous stable record bandwidth ≥3GB/s; continuous stable reading bandwidth ≥ 3GB/s |
| Data interface | Backboard: 12 Road GTH, support SRIO, Aurora protocol |
| Control interface | Front panel: 1 Gigabit network port |
| File management | Standard file system (EXFAT file system) |
| Control protocol | The network adopts a standard FTP communication protocol; supports standard FTP tools to access file access |
| Download bandwidth | Gigabit network port ≥100MB/s; 10,000MB/s |
| Software function | Real -time recording functions, data release functions, data access, file online management function, self -test and fault detection function, abnormal tolerance protection mechanism and other functions. |
| Operating temperature | Standard temperature: 0 ℃ to+55 ℃ Military temperature: -40 ° C to+70 ° C (optional, only partial hard disk, decreased bandwidth) |
| Cooling method | Compatible wind and cold and cold, support structure customization |
| Consumption | Full load run ≤30W |
| Size | 233.4mm × 160mm ×24mm |
Block diagram
Ordering Guide
| Serial number | Order model | Configuration |
| 1 | FK-LRMKU-M2S1-2T | 2TB storage capacity, ≥2GB bandwidth |
| 2 | FK-LRMKU-M2S2-2T | 2TB storage capacity, ≥4GB bandwidth |
| 3 | FK-LRMKU-M2S1-4T | 4TB storage capacity, ≥2GB bandwidth |
4 | FK-LRMKU-M2S1-8T | 8TB storage capacity, ≥2GB bandwidth |
