FKG-FMCK7-M2
◆ | National production design, RAID 0 in the 2nd disk group, provides multiple high -speed data interfaces to the outside world; |
◆ | Adopting Fengke NVME storage architecture, FTP or network disk access function can be provided through Gigabit/Mercedescent network ports; |
◆ | It has the characteristics of national, low power consumption, small size, and provides the characteristics of standard Exfat file systems. It can be widely used in data collection and record storage and data management in related fields; |
Download：Product specifications
Product features
-
The localization of FMC module -
4 TB storage capacity -
2 gb/S memory bandwidth -
For exFAT file system
Detailed parameters
| Product form | Single width fmc subcard |
| Storage | Support 2 M.2 interfaces NVME SSD; Standard Edition 2TB, Maximum 4TB supports 4TB |
| Storage bandwidth | Continuous stable record bandwidth ≥2gb/s; continuous stable reading bandwidth ≥2gb/s |
| Data interface | FMC plugin: 4 GTH, support SRIO, Aurora protocol |
| Control interface | FMC plug -in: 1 Wanzaro port/1 Gigabit network port |
| File management | Standard file system (EXFAT file system) |
| Control protocol | The network adopts a standard FTP communication protocol; supports standard FTP tools to access file access |
| Download bandwidth | Gigabit network port ≥100MB/s; 10,000MB/s |
| Software function | Real -time recording functions, data release functions, data access, file online management function, self -test and fault detection function, abnormal tolerance protection mechanism and other functions. |
| Operating temperature | Standard temperature: 0 ℃ to+55 ℃ Military temperature: -40 ° C to+70 ° C (optional, only partial hard disk, decreased bandwidth) |
| Cooling method | Compatible wind and cold and cold, support structure customization |
| Consumption | Full load run ≤30W |
| Size | 92mm × 69mm |
Block diagram
Ordering Guide
| Serial number | Order model | Configuration |
| 1 | FK-FMCK7-M2S1-2T | 2TB storage capacity, ≥2GB bandwidth |
| 2 | FK-FMCK7-M2S1-4T | 4TB storage capacity, ≥2GB bandwidth |
