FKG-VPXV7-M8

◆

Standard 6U 5HP VPX architecture products, 8 disk group RAID 0, providing multiple high -speed data interfaces to the outside world;

◆

Adopting Fengke NVME storage architecture, FTP or network disk access functions can be provided through Gigabit/10,000 -Dibin port ports. Through the PCIE interface, you can directly read and write the storage data data. There is no need to transfer;

◆

It has the characteristics of high bandwidth, large capacity, and providing standard EXFAT file systems, and can be widely used in data collection records storage and data management in related fields;


Product features
  • Localization module
  • The standard 6 u VPX architecture
  • 16 TB storage capacity
  • 7 gb/S memory bandwidth
Detailed parameters
Product formStandard 6U VPX architecture, height 5HP
StorageSupport 8 M.2 interfaces NVME SSD; capacity supports 4TB/8TB/16TB multiple specifications to option
Storage bandwidthContinuous stable record bandwidth ≥7GB/s; continuous stable reading bandwidth ≥7GB/s
Data interfaceBackboard P1: 16X Gth
Control interfaceFront panel: Road Wanzar.com, 1 Gigabit Network port; P2: DCIEX4
File managementStandard file system (EXFAT file system)
Control protocolThe network adopts a standard FTP communication protocol; supports standard FTP tools to access file access
Download bandwidthGigabit network port ≥100MB/s; 10,000MB/s
Software functionReal -time recording functions, data release functions, data access, file online management function, self -test and fault detection function, abnormal tolerance protection mechanism and other functions.
Operating temperature

Standard temperature: 0 ℃ to+55 ℃

Military temperature: -40 ° C to+70 ° C (optional, only partial hard disk, decreased bandwidth)

Cooling methodCompatible wind and cold and cold, support structure customization
ConsumptionFull load run ≤70W
Size233.35mm × 160mm ×25mm


Block diagram
Ordering Guide
Serial numberOrder modelConfiguration
1FK-VPXV7-M8S1-4T4TB storage capacity, ≥ 4GB bandwidth
2FK-VPXV7-M8S2-4T4TB storage capacity, ≥7GB bandwidth
3FK-VPXV7-M8S1-8T8TB storage capacity, ≥4GB bandwidth

4

FK-VPXV7-M8S1-16T16TB storage capacity, ≥4GB bandwidth
